Early 90's Jeep Vacuum Diagram?

[Juan_Hong_Loe]

Anybody got one for the vacuum actuator on the front axle/transfer case/etc. I seem to have something backwards cause it actuates when engine is running.



[3 tons o fun]

I wonder if the vaccum is pushin instead of pulling or vice versa.



[Juan_Hong_Loe]

All's I know it don't work right. So if I can see a diagram maybe that will help. I do have one of those Chilton repair manuals and it doesn't have shiat for a diagram in there.



[Juan_Hong_Loe]

ttt



[Speeding]

Does this help at all?

For an 87-90 YJ

This is for a 91-95YJ



[Rescue1]

http://forums.off-road.com/jeep-short-wheelbase/7020-qudratrack-emergency-handle-vacuum-lines-diagram.html

This might help

http://www.jubileejeeps.org/quadratrac/index.htm
This might help too.



[Juan_Hong_Loe]

Does this help at all?

For an 87-90 YJ

This is for a 91-95YJ

Well, yeah!

I have been looking for a couple of hours and all the images on the forums that I've found are not showing up for some reason, and Ricky finds it in two seconds. WTF? I R Dum.



[3 tons o fun]

Well, yeah!

I have been looking for a couple of hours and all the images on the forums that I've found are not showing up for some reason, and Ricky finds it in two seconds. WTF? I R Dum.

SSSSSDUMB!!!!!
