Fuel Cell Pickup Location

FM5332FF · Dec 21, 2014

I'm finally at the point in my build where I need to start on the fuel system for my buggy, my neighbor is an aluminum fabricator and said he will build my fuel cell for me for the cost of materials. So pretty much I need to know what I should do for fuel pickups before I go ahead and have him build me my fuel cell. Will a bottom sump facing towards the rear be alright if so how deep and will this starve my fuel cell of fuel if i am to drive down hill ? Or should I run walbro pickups inside of the tank? with either setup the tank will be baffled to minimize fuel sloshing. Any input is welcome. I will be running a 5.3 vortec motor. Thanks.

infamous1 · Dec 21, 2014

Re:

Mine has a front sump to facilitate routing fuel lines better, with a 3/8 tube ran to the back of the cell and foam blocks stuffed in there to minimize slosh. Never had an issue but I'm not big on much downhill stuff either!!

b.boyd · Dec 24, 2014

I run four Walbro pick ups in each corner...never a problem.

The-Boss · Dec 24, 2014

Depending on how long you still have to install a pickup you might want to wait for Holleys new Hydramat to be available.

https://www.youtube.com/watch?v=4rG97UuVgmQ

https://www.youtube.com/watch?v=yfE1v65fNZI

John Galbreath Jr. · Dec 24, 2014

That hydromat is a very cool item.

Sent from my iPad using Tapatalk with my left thumb.

BUG-E J · Dec 25, 2014

JohnG said:
That hydromat is a very cool item.

Sent from my iPad using Tapatalk with my left thumb.

:****:

sledneck · Dec 25, 2014

X4 this is going to be the way to go. When I build my new fuel cell this is what will be going in it.

FM5332FF · Jan 13, 2015

Any other options?

s.frimodt · Jan 14, 2015

Here's how I did mine 4 years ago, runs like a peach at all the angles it can stand on without falling over. Even with the fuelgauge showing way low. Basic and made out of various pieces of scrap. But works really well. Suction Tube is of course in the middle of it all.

wizzo · Jan 14, 2015

I run the walbro pickups in all 4 corners, had great luck with them, can't really say anything bad about them. But I would definitely consider the new holley stuff if you can wait or a surge tank from ATL. Check out part#ST528 here: http://www.atlinc.com/pdfs/Racing/ATL-2014-Catalog-Page19.pdf I'm pretty sure BJ Allen (crawlin85cj) has run the surge tank i'm talking about in one of his buggies.

Or have your guy build a trap system like s.frimodt posted but i would run an in tank fuel pump with a sock and put it down in the center of the trap. I definitely wouldn't do a bottom sump only.

Are you planning on running foam? Your tank design may dictate what will work best for you.

rpf500 · Jan 14, 2015

Checked the website for Holley:

Coming Soon (Expected Availability Feb. 15)
Sign Up for HydraMat Email Updates

infamous1 · Jan 14, 2015

Re:

Any pricing info yet??

Mortalis5509 · Jan 14, 2015

Re:

I'm looking at different option from pick up to dual pumps, but it needs to support up to the 900hp range due to using e85. I'm using plastic baffling. I would also like to run a sending unit for a fuel guage

krahn · Feb 18, 2015

Anybody hear updates on that Hydramat and when it will be available? Feb. 15th and still not available for purchase.

wizzo · Feb 18, 2015

last i saw they were still taking info on what sizes people want so they make the sizes that would sell. i think you can email them or something to get on a list for when they are ready.

krahn · Feb 18, 2015

Yep. Still the same status but I've not seen any updates. Been on the list since Dec. I'll call later today and see if I can get any info.

paradisepwoffrd · Feb 18, 2015

They had a press release today announcing how many cars were using it in the ARCA Daytona race, but nothing yet as far as selling it. And I would like the 1 size they have listed now.

krahn · Feb 18, 2015

I tried calling but there was a 30 minute wait for product sales and I didn't have that much time. That press release must have generated some activity for them.
