Identify Front Axle , not sure what i got

SJR · Sep 17, 2009

this is a A axle I got it has 6 bolt hubs not sure what it is Help!!

one hub looks to be aluminum and one steel?? , I have the hubs somewhere and the bearings are shot or maybe just need adjusted
wondering what it is I got it on a 80 Datsun pickup that was obviously modified think the truck origanaly was 2wd , thanks everyone

wishicouldwheel · Sep 17, 2009

axle

looks to be a narrow dana 44...got the flat top knuckle..

Bodaciouscj7 · Sep 17, 2009

x2 but I dont recall a 44 with solid rotors

junkyard jim · Sep 17, 2009

Def Chev or a drilled knuckles and it's SOA (can't see the bottom to tell if that's original or not) Maybe IH Scout? Dodge/Chev cut down?

Ramtime · Sep 18, 2009

looks like some scap steel to me. I can come pick it up for you!

TreeClimber · Sep 18, 2009

Google : Datsun 4x4 conversion

It looks a Dana front axle, and by the looks of the steering knuckle a D44. However it's tough to tell, as Dana made D25 / D27 / D30 all in a steering configuration which could have been made for a high-steer scenario. However my guess is the axle is late 70s, ergo it's a D30 or D44. I'd guess D44.

CHOP SHOP · Sep 18, 2009

TreeClimber said:
Google : Datsun 4x4 conversion

It looks a Dana front axle, and by the looks of the steering knuckle a D44. However it's tough to tell, as Dana made D25 / D27 / D30 all in a steering configuration which could have been made for a high-steer scenario. However my guess is the axle is late 70s, ergo it's a D30 or D44. I'd guess D44.

You are correct sir.

Most likely a D30.

boardbysled · Sep 18, 2009

SOA older waggy axle? maybe a waggy axle with stock flattops?

edit: an its got a yota steering box still attached? maybe a franken axle then...

2nd edit: never mind, its a saginaw box, i will stick with my frankenstien older waggy axle theory...

pokey · Sep 18, 2009

CHOP SHOP said:
You are correct sir.

Most likely a D30.

I would agree as well. There were several companys making these axles out of jeep axles to fit into mini truck conversions. Many of the parts are kobbeled together from differant mfgs. and can be very difficult to find parts for.

hotrod1 · Sep 18, 2009

take better pictures

crash2 · Sep 18, 2009

I remember a number of years ago I bumped into a guy up at reiter(maybe 10years ago) he had some d30 under his datsun that was part of some kit he had bought. Didn't think I would evere hear of such a thing again.

PUO-BANNED · Sep 18, 2009

better pics needed. but look at the center section and how it has that extra pad cast into it. most likely a dana 30

zukkev · Sep 18, 2009

one of our guys sold one of these at the swap meet last yr ('08)....Dana 30...It came out from under a 78 Datsun 4x4 (conversion obviously); had the same knuckles as this one---also had the same 6bolt hubs and solid rotors...

SJR · Sep 18, 2009

so maybe a Dana 30? what would that came in early 70s Jeep?

JOOP · Sep 18, 2009

Skinny leafs, so an older CJ or Scoutm Dana 30 or 27. Need a pic of the center section.

The flat top knuckles are worth something. The rest looks like good lawn dart.

SJR · Sep 18, 2009

the truck was a hack job not factory

Damnyankee · Sep 18, 2009

it definatly could have been one of the datsun 4x4 conversions.

looks exactly like the one under my buddies datsun

CHOP SHOP · Sep 18, 2009

SJR said:
the truck was a hack job not factory

They are a hack job from the factory!! True fact.

That front was never in a jeep and then put in a hacker. It has solid metric brake discs that never came on a d30 untill WOLVERINE conversions got their hands on them.

I have had three trucks from wolverine

A datsun, a courrier, and a HiLux. I am not making assumptions or educated guesses.

Heres one of the toyotas I parted. The toyotas are even stranger, they have a five lug front to match the five lug 2X rear end. Same shitty brakes and hoaky histeer arm. Some of the arms are welded on the knuckle too.

Heres one I gave the torch to.

Bunk1 · Sep 18, 2009

JOOP said:
The flat top knuckles are worth something.

Exactly what i was thinking.

CHOP SHOP · Sep 18, 2009

boardbysled said:
SOA older waggy axle? maybe a waggy axle with stock flattops?

edit: an its got a yota steering box still attached? maybe a franken axle then...

2nd edit: never mind, its a saginaw box, i will stick with my frankenstien older waggy axle theory...

Thats no saginaw box homie.
