Front driveshaft options

Mitchell Ex · Nov 18, 2014

http://www.wideopendesign.com/Product/11196/Drive-Shaft-Carrier-Bearing.aspx This should do the trick

RebelRider · Nov 18, 2014

Mitchell Ex said:
http://www.wideopendesign.com/Product/11196/Drive-Shaft-Carrier-Bearing.aspx This should do the trick

I don't have the room for a 2 PC.

Rokcrler · Nov 18, 2014

Re:

On the Toyota I had to limit droop after the ton swap due to the toy joint binding. I'm running a 2 piece shaft

RebelRider · Nov 18, 2014

My drivetrain was a lot longer with the toy stuff, but with the 4L80/atlas putting a 2pc would make the final shaft really short at a steep angle.

bee513 · Nov 18, 2014

tommy450r said:
An here it is all together

i ran the pto sutff before and the splines twisted when i linked it i used factory slip

kushKrawlin · Nov 19, 2014

tommy450r said:
This is redneck but I took a pto shaft extension an cut the female splines off about 1/2 inch from the male splines an turned it down to a press fit in the dom then I took a 1350 slip yoke cut the tube off of it an opened the center up as much as I could to make it press fit on the male splines.

That may not make since but I got pics if anybody needs em. I ended up with about 12 inches of splines for the slip joint an the splines are almost 1 3/4" so it should hold up.

Hmmm.. u call it redneck, I call it dam near genius.. Some of yall really make me feel dumb sometimes. Dam modern day McGivers! :dblthumb:

And don't doubt the 1310's to bad. I have read ALOT about them being strong and holding up. Mine still is! I always have a spare tho. Keep posted on wat Ya do. In the near future I will be puttin atlas under my rig, lord knows that could be a nightmare. I don't even wanna think bout it.

RebelRider · Nov 20, 2014

So, I've decided to order a toyota output flange for the atlas. I'm going to try and run a toyota cardine joint up top since it's such a steep angle. I will also for sure be limiting my droop.
Any suggestions on where to buy the flange besides high angle driveline? Must be 32 spline.

Neal3000 · Nov 20, 2014

RebelRider said:
So, I've decided to order a toyota output flange for the atlas. I'm going to try and run a toyota cardine joint up top since it's such a steep angle. I will also for sure be limiting my droop.
Any suggestions on where to buy the flange besides high angle driveline? Must be 32 spline.

I made that mistake when i first put my atlas in, spent my money on toy flanges so i could keep my toy d-shafts front and rear and they quickly became the weak link, first the rear, then the front.

TBItoy · Nov 20, 2014

Re: Re: Re: Front driveshaft options

RebelRider said:
So, I've decided to order a toyota output flange for the atlas. I'm going to try and run a toyota cardine joint up top since it's such a steep angle. I will also for sure be limiting my droop.
Any suggestions on where to buy the flange besides high angle driveline? Must be 32 spline.

I wouldn't do that.

RebelRider · Nov 20, 2014

Neal3000 said:
I made that mistake when i first put my atlas in, spent my money on toy flanges so i could keep my toy d-shafts front and rear and they quickly became the weak link, first the rear, then the front.

Yea, I was just informed this wouldn't be a good idea. I'm going to try and run a single joint 1350 on both ends. I'll possibly need to move to 1410.

TBItoy · Nov 20, 2014

RebelRider said:
Yea, I was just informed this wouldn't be a good idea. I'm going to try and run a single joint 1350 on both ends. I'll possibly need to move to 1410.

If you are buying new stuff, might as well go 1410. Stronger and more angle.

RebelRider · Nov 24, 2014

I've been doing some grinding on my 1350 non-cv yoke. It definitely helps gain more angle but doesn't seem to be enough. Should a switch to the cv style or 1410?
Would I gain a noticeable amount of angle going with a 1410?
